ステンレス製フルハイトターンスタイル
IM.Q805
IM.Q805 Full Height Turnstile is a completely ergonomic product with excellent structural integrity, which provides the optimum level of security and perfectly combines with numerous methods of identity verification. It is designed to be highly controlled in access control in high security areas, and it has advanced features in order to prevent unauthorized access.
-
アームレングス : 500ミリメートル
-
通路幅 : 550-600ミリメートル
-
追い越し速度 : ≤ 35 人/分
-
材料 ：304 Stainless Steel Material
-
寸法 : 長さ 2530* 幅 1550* Height 2170mm
顔認識
LEDディスプレイ
8 赤外線検出器のペア
QR
The stainless steel full height turnstile offers a strong and weatherproof access control to pedestrians. Constructed using high grade SUS304 stainless steel, it is resistant to corrosion, impact and temperature variations thus it can be used in outdoors locations like factory gates, military compounds and logistics centers. The full-height swiveling arms formed a total physical barrier between the floor and the ceiling and guarantee each movement.
This turnstile will aid in anti-tailgating detection and reverse-entry. In case of abnormal behavior, it will immediately generate the alerts and block the passage. The users move through the lane with LED indicators and voice prompts, which minimize confusion and improves throughput. These are user friendly indicators that enhance safety and efficiency.
The stainless steel full height turnstile can easily be integrated with an array of verification solutions such as RFID readers, QR code scan, biometric sensors and face recognition terminals. さらに, there are centralized access control platforms that are able to monitor, record and control user permissions remotely.
There is also the emergency fail-safe in the system. It is also unlocked by default in case of a fire alarm or cut power supply, and one can evacuate swiftly and safely. Its internal design is easy to maintain as it is modular and is also reliable to operate on a daily basis.
特徴
- Fully height barrier does not allow climbing, tailgating and reverse entry.
- 統合- Anti-tailgating detection and visual/audio alert.
- Constructed out of SUS304 stainless steel and an anti-corrosion coating.
- RFID compatible with biometric terminals, QR terminal and facial ID terminal.
- Unlocked by a fire alarm or a power cut.
- Supports single or bi-directional flow of access.
- Status lights and voice guidance controls to ease navigation.
- Internal structure is designed in a modular way to simplify servicing.
- 製品詳細
- 仕様
- 技術的および特徴
- 適応性
- アプリケーション
製品詳細
業界グレードの素材と構造
The stainless steel full height turnstile combines industrial-grade materials with intelligent control to deliver uncompromising access security. It ensures single-person entry while resisting harsh weather and unauthorized access in high-risk outdoor environments.
- 材料: 304 ステンレス鋼素材, トップボックスとガードレールの厚さ 1.2mm, 回転アームの厚さ 2.0mm
- 耐食性: ISOに合格 9227 塩水噴霧テスト (2,000 何時間も錆びずに)
- 温度範囲: -30Cから+70C (屋内外互換性)
- 保護等級: 防水・防塵性 (激しい雨や砂塵の中での安定した動作)
仕様
コア技術仕様
| 寸法 | 長さ 2530* 幅 1550* 高さ:2170mm |
| アームレングス | 500ミリメートル |
| パス方向 | 一方通行および双方向の支援 (随意) |
| 追い越し速度 | ≤ 35 人/分 |
| 通路幅 | 550-600ミリメートル |
| 電源電圧 | AC110-220±10%V 50HZ |
| 駆動電流 | > 200だがしかし |
| 統合 | IDカード/ICカード/QRコード認識/RS485/リレーインターフェースをサポートしています |
技術的および特徴
技術的およびセキュリティ機能
スマートアクセス制御システム
Unique Design：
The turnstile adopts a unique appearance and structural design, which is not only beautiful and elegant, can integrate with various architectural environments, and enhance the overall image of the place, but also more in line with ergonomics in structural layout, facilitating personnel to pass quickly and smoothly.
High Security：
It has extremely high safety performance, is made of high-strength and durable materials, can withstand large impact forces, and effectively prevent man-made damage. 同時に, it is equipped with a precise detection device that can monitor the channel status in real-time, and once an abnormal situation is found, the corresponding safety mechanism will be activated immediately.
Anti-Reverse & アンチ・テールゲーティング:
The turnstile is designed with anti-reverse and anti-tailgating functions. The anti-reverse function can prevent personnel from passing through the turnstile in the opposite direction, avoiding confusion in entry and exit management. The anti-tailgating function can effectively prevent multiple people from following one authorized person to pass through, ensuring that only one person can pass through each time after successful identification, thus ensuring the strictness of access control.
Support for Multiple Identification Methods：
It supports multiple identity recognition methods such as fingerprint recognition, card swiping recognition (such as IC card, ID card), 顔認識, password recognition, 等. Users can flexibly choose according to actual needs, meet the use requirements in different scenarios, and improve the convenience and flexibility of channel management.
適応性
グローバル市場適応力
- 電圧: 100-240V広域入力 (グローバルグリッド互換性)
- 言語サポート: 24/7 イギリスでの任務
- 証明: それ,FCC,ISO9001
アプリケーション
応用シナリオ
- 工業用地
- 交通の要所
- スタジアムとアリーナ
- 刑務所と矯正施設
- データセンター
